CONTEMPORARY
The Contemporary garage door series, immaculately constructed, offers the texture and aesthetic of real wood panels with excellent thermal efficiency.
ABOUT OUR COLOURS
Every door is finished with a factory applied, baked on, two coat polyester paint finish giving years of maintenance free operation.
The door may also be painted to suit the exterior colour specifications of your home.
Click here for Painting Instructions
Note: The accuracy of the colours displayed may vary depending on the settings of your monitor. To obtain an exact colour reference, please contact a Steel-Craft dealer for colour samples.
Please Note: Elite Finish in Charcoal is only available in standard heights of 7′, 8′, 9′ & 10′.
CONTEMPORARY DOOR SIZE CHART
The Contemporary R-16 is 1-3/4” thick and comes in standard heights of 6’ through 10’, with the standard headroom requirement of 12”, however low headroom kits are available for special applications.
Height
- 6'
- 7' *
- 7'3"
- 7'6"
- 7'9"
- 8' *
- 8'9"
- 9' *
- 9'3"
- 9'6"
- 9'9"
- 10' *
8' wide
- 8'x6'
- 8'x7'
- 8'x7'3"
- 8'x7'6"
- 8'x7'9"
- 8'x8'
- 8'x8'9"
- 8'x9'
- 8'x9'3"
- 8'x9'6"
- 8'x9'9"
- 8'x10'
9' wide
- 9'x6'
- 9'x7'
- 9'x7'3"
- 9'x7'6"
- 9'x7'9"
- 9'x8'
- 9'x8'9"
- 9'x9'
- 9'x9'3"
- 9'x9'6"
- 9'x9'9"
- 9'x10'
10' wide
- 10'x6'
- 10'x7'
- 10'x7'3"
- 10'x7'6"
- 10'x7'9"
- 10'x8'
- 10'x8'9"
- 10'x9'
- 10'x9'3"
- 10'x9'6"
- 10'x9'9"
- 10'x10'
12' wide
- 12'x6'
- 12'x7'
- 12'x7'3"
- 12'x7'6"
- 12'x7'9"
- 12'x8'
- 12'x8'9"
- 12'x9'
- 12'x9'3"
- 12'x9'6"
- 12'x9'9"
- 12'x10'
14' wide
- 14'x6'
- 14'x7'
- 14'x7'3"
- 14'x7'6"
- 14'x7'9"
- 14'x8'
- 14'x8'9"
- 14'x9'
- 14'x9'3"
- 14'x9'6"
- 14'x9'9"
- 14'x10'
16' wide
- 16'x6'
- 16'x7'
- 16'x7'3"
- 16'x7'6"
- 16'x7'9"
- 16'x8'
- 16'x8'9"
- 16'x9'
- 16'x9'3"
- 16'x9'6"
- 16'x9'9"
- 16'x10'
18' wide
- 18'x6'
- 18'x7'
- 18'x7'3"
- 18'x7'6"
- 18'x7'9"
- 18'x8'
- 18'x8'9"
- 18'x9'
- 18'x9'3"
- 18'x9'6"
- 18'x9'9"
- 18'x10'
* Elite Finish in Charcoal is only available in standard heights of 7', 8', 9' and 10'.
NUMBER OF SECTIONS
| DOOR HEIGHT | NUMBER OF 21" SECTIONS | NUMBER OF 24" SECTIONS | TOTAL SECTIONS |
|---|---|---|---|
| 6' | 3 | 3 | |
| 7' | 4 | 4 | |
| 7'3" | 3 | 1 | 4 |
| 7'6" | 2 | 2 | 4 |
| 7'9" | 1 | 3 | 4 |
| 8' | 4 | 4 | |
| 8'9" | 5 | 5 | |
| 9" | 4 | 1 | 5 |
| 9'3" | 3 | 2 | 5 |
| 9'6" | 2 | 3 | 5 |
| 9'9" | 1 | 4 | 5 |
| 10' | 5 | 5 |
CHARCOAL NUMBER OF SECTIONS
| DOOR HEIGHT |
NUMBER OF 21" SECTIONS |
NUMBER OF 21.6" SECTIONS |
NUMBER OF 24" SECTIONS |
TOTAL SECTIONS |
|---|---|---|---|---|
| 7' | 4 | 4 | ||
| 8' | 4 | 4 | ||
| 9' | 5 | 5 | ||
| 10' | 5 | 5 |
PLAIN LITE
Available in 5/8” ThermoPane.
Please Note: Sandstone is only available in window sizes 26″x14″ and 38″x14″.
Window sizes available in Contemporary 24″x 6″, 26″x 14″ and 38″ x 14″.
Available in 5/8” ThermoPane.
Aligmnent available in Left Vertical Column, Right Vertical Column and Top Horizontal Row.
Note: Bottom section window will only be installed on the top of the section.
